Model No.: HSB-75NC
Machinable material: Alloy, Brass / Copper, Carbon Steel, Stainless Steel, Aluminum
Old and new: New
place of origin: China
degree of automation: Semi-Automatic
Additional features: End Forming
Certification: Ce
warranty period: 1 Year
Out-of-warranty service: Video Technical Support, Online Support
Core selling point: Multifunctional
Applicable industry: Building Material Shops, Machinery Repair Shops, Farms, Manufacturing Plant, Construction Works, Energy &Amp; Mining, Other
Where to provide local services (in which countries are there overseas service outlets): None
Showroom location (in which countries are there sample rooms overseas): None
Marketing type: Ordinary Product
Mechanical test report: Provided
Video factory inspection: Provided
Core component warranty period: 1 Year
Core components: Bearing, Motor, Pump, Gear, Plc, Pressure Vessel, Engine, Other, Gearbox
Packaging: standard wooden cases
Productivity: 30sets/month
Brand: Heshun
Transportation: Ocean,Express,Express
Place of Origin: China
Supply Ability: 30 sets/month
Certificate: CE
HS Code: 8462299000
75NC Pipe Bending Machine
1.Product Introduction:
We are a manufacturer of pipe processing machines. Including pipe bending machine, pipe cutting machine,pipe chamfering machine and pipe end forming machines.
This is our 75nc pipe bending machine, the feature is as follows:
1. NC control unit
2. Direct acting hydraulic clamping
3. Manual feeding and bending
4. Can make 2-dimensional elbow bend
5. Easy operaton interface and easy data input
6. Large program storage capacity up to 16 units
7. Automatically lock angle, angle changing is controlled by coder
8. High bending accuracy
9. Self diagnosis and error messages
10. Fit for carbon steel pipe, stainless steel pipe, aluminium pipe, copper pipe, galvanized pipe, etc.
2.The technical parameters:
Item 75NC
Max.applicable carbon steel pipe material Φ76.2*3.0t
Max.applicable stainless steel tubing Φ69.85*1.9t
penetration length 2900mm
Max.bending radius 250mm-300mm
Max. bending angle 185°
Number of bends 16
Max. oil pressure 14mpa
Motor power 7.5KW
Weight 2600KG
Size(LWH,mm) 4000*1100*1250
